10G 300M 850nm SFP+
The transceiver is designed for using in 10.3Gb/s data rate over multimode fiber. The
transceiver is compliant with SFF-8431, and the mechanical SFP28 plug is compatible with
SFF-8432. Digital diagnostics functions are available via a 2-wire serial interface, as
specified in SFF-8472.
Product Features
Standard Compliance & Compliance Certifications
Compliant to SFP+ MSA
Fully RoHS Compliant
Digital Monitoring SFF-8472 Rev 10.2 compliant
Data & Transmission
Operating data rate up to 10.52 Gbps
Maximum link length of 300 m on OM3 MMF
Mechanical & Interface
All metal housing for superior EMI performance
LC duplex connector
Hot pluggable 20-pin connector
Electrical & Power
Single +3.3V±5% power supply
Low power consumption < 1 W
Operating Temperature Options
0℃ to 70℃ operating wide temperature range
Applications
- 10G Ethernet
- 10GBASE-SR/SW 10GBASE-SR10GBASE-SR
- OBSAIrates 6.144 Gb/s,3.072Gb/s,1.536 Gb/s, 0.768Gb/s
- CPRIrates 7.373Gb/s, 6.144Gb/s,4.915 Gb/s, 2.458 Gb/s,1.229 Gb/s,0.614Gb/s SFP+ MSA (SFF-8472)
- IEEE802.3ae
Information Form
| Part Number | Package | Date rate | Laser | Optical Power | Detector | Temp | Reach | Other | Application |
|---|---|---|---|---|---|---|---|---|---|
| SOT-M-10G-850-300M | SFP+ | 8.5 ~ 10.52dBm | 850nm | -5~1dBm | PIN(COB) | 0 ~ 70 °C | 300m | DDM | 10GBASE-SR 8G/10GFC |
